U7-OUTDOOR

Mechanical Dimensions 170 x 208 x 54.5 mm (6.7 x 8.2 x 2.1?) Weight 1.2 kg (2.6 lb) Enclosure material UV-stabilized polycarbonate, aluminum alloy Mount material Polycarbonate, SGCC steel Pole mount diameter 25–60 mm (1–2.36?) on pipe outer diameter Wind survivability 74.6 N at 200 km/h (16.8 lbf at 125 mph) Weatherproofing IPX6 Hardware Networking interface (1) 1/2.5 GbE RJ45 port Management interface Ethernet Power method PoE+ Power supply UniFi PoE Switch Supported voltage range 42.5—57V DC Max. power consumption 19W Max. TX power 2.4 GHz 5 GHz 6 GHz 23 dBm 26 dBm – MIMO 2.4 GHz 5 GHz 6 GHz 2 x 2 (DL/UL MU-MIMO) 2 x 2 (DL/UL MU-MIMO) – Max. data rate 2.4 GHz 5 GHz 6 GHz 688 Mbps (BW40) 4.3 Gbps (BW240) – Antenna gain 2.4 GHz 5 GHz 6 GHz Directional internal: 8 dBi/External omni: 3 dBi Directional internal: 12.5 dBi/External omni: 4 dBi – Antenna beamwidth 2.4 GHz 5 GHz 6 GHz 90° 45° – Antennas (1) Directional internal antenna (2) External omni antennas (2) RP-SMA connectors for external antenna LEDs (1) Power: white/blue (4) Mesh signal: blue Button Factory reset Mounting Wall, ceiling, pole (Included) Ambient operating temperature -30 to 60° C (-22 to 140° F) Ambient operating humidity 5 to 95% noncondensing Certifications CE, FCC, IC Software WiFi standards 802.11a/b/g/n/ac/ax/be (WiFi 6, WiFi 7) Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) BSSID 8 per radio VLAN 802.1Q Advanced QoS Per-user rate limiting Guest traffic isolation Supported Concurrent clients 200+ Supported Data Rates 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) 802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160) 802.11be (WiFi 7) 7.3 Mbps to 4.3 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240)
