U7-lite

Compact, ceiling-mounted WiFi 7 AP with 4 spatial streams and 2.5 GbE uplink. Overview Dimensions Ø171.5 x 33 mm (Ø6.8 x 1.3?) WiFi Standard WIFi 7 Spatial Streams 4 Coverage Area 115 m² (1,250 ft²) Max. Client Count 200+ Uplink 2.5 GbE Mounting Ceiling, Wall (Lite Mount Included) Power Method PoE Performance MIMO 5 GHz 2 x 2 (DL/UL MU-MIMO) 2.4 GHz 2 x 2 (DL/UL MU-MIMO) Max. Data Rate 5 GHz 4.3 Gbps (BW240) 2.4 GHz 688 Mbps (BW40) Antenna Gain 5 GHz 5 dBi 2.4 GHz 4 dBi Max. TX Power 5 GHz 24 dBm 2.4 GHz 23 dBm Max. BSSIDs 8 per Radio Supported Data Rates 802.11be (WiFi 7) 7.3 Mbps to 4.3 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240) 802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160) 802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160) 802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) Features Wireless Meshing ? Band Steering ? 802.11v BSS Transition Management ? 802.11r Fast Roaming ? 802.11k Radio Resource Management (RRM) ? Advanced Radio Management ? Passpoint (Hotspot 2.0) ? Captive Hotspot Portal Custom Branding Landing Page ? Voucher Authentication ? Payment-Based Authentication ? External Portal Server Support ? Password Authentication ? Guest Network Isolation ? Private Pre-Shared Key (PPSK) ? WiFi Speed Limiting ? Client Device Isolation ? WiFi Schedules ? RADIUS over TLS (RadSec) ? Dynamic RADIUS-assigned VLAN ? Hardware Max. Power Consumption 13W Supported Voltage Range 42.5—57V DC Networking Interface (1) 2.5 GbE RJ45 port Weight 313 g (11 oz) Management Ethernet Enclosure Material UV-stabilized polycarbonate Mount Material UV-stabilized polycarbonate, galvanized steel (SGCC) LEDs System White/Blue Channel Bandwidth HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz) NDAA Compliant ? Certifications CE, FCC, IC, Anatel Ambient Operating Temperature -30 to 40° C (-22 to 104° F) Ambient Operating Humidity 5 to 95% noncondensing Software Application Requirements UniFi Network Version 9.0.114 and later Mobile App iOS™ version 10.20.2 and later Android™ version 10.21.7 and later
