U7-PRO

Ceiling-mounted WiFi 7 AP with 6 spatial streams and 6 GHz support for interference-free WiFi in demanding, large-scale environments. WiFi 7 with 6 GHz support 6 spatial streams 140 m² (1,500 ft²) coverage 300+ connected devices Powered using PoE+ 2.5 GbE uplink Mechanical Dimensions Ø206 x 46 mm (Ø8.1 x 1.8?) Weight 680 g (1.5 lb) Enclosure material Polycarbonate, metal Mount material Stainless steel (SUS304), galvanized steel (SGCC) Hardware Networking interface (1) 1/2.5 GbE RJ45 port Management interface Ethernet Power method PoE+ Power supply UniFi PoE switch Supported voltage range 44—57V DC Max. power consumption 21W Max. TX power 2.4 GHz 5 GHz 6 GHz 22 dBm 26 dBm 23 dBm MIMO 2.4 GHz 5 GHz 6 GHz 2 x 2 (DL/UL MU-MIMO) 2 x 2 (DL/UL MU-MIMO) 2 x 2 (DL/UL MU-MIMO) Max. data rate 2.4 GHz 5 GHz 6 GHz 688 Mbps (BW40) 4.3 Gbps (BW240) 5.7 Gbps (BW320) Antenna gain 2.4 GHz 5 GHz 6 GHz 4 dBi 6 dBi 5.8 dBi LEDs White/blue Button Factory reset Mounting Wall/ceiling (Included) Ambient operating temperature -30 to 60° C (-22 to 140° F) Ambient operating humidity 5 to 95% noncondensing Certifications CE, FCC, IC Software WiFi standards 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7) Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) BSSID 8 per radio VLAN 802.1Q Advanced QoS Per-user rate limiting Guest traffic isolation Supported Concurrent clients 300+ Supported Data Rates 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) 802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6/6E) 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160) 802.11be (WiFi 7) 7.3 Mbps to 5.7 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240/320) Application Requirements UniFi Network Version 8.0.26 and later UniFi OS Version 3.2 and later
