> 8MP, 1/2.8” CMOS image sensor, low illuminance, high image definition > Outputs max.8MP (3840 × 2160) @20 fps (AI function enabled by default)and supports 8MP (3840 × 2160) @25/30 fps (when AI function disabled) > H.265 codec, high compression rate, low bit rate > Built-in warm illuminator, and the max. illumination distance: 30 m > ROI, Smart H.265+/Smart H.264+, flexible coding, applicable to various bandwidth and storage environments > Rotation mode, WDR, 3D NR, HLC, BLC, digital > watermarking, applicable to various monitoring scenes > Intelligent detection: Intrusion, tripwire (support the classification and · accurate detection of vehicle and human) > Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection > Supports sound and light alarm linkage. When an alarm is triggered, the camera links sound alarm and light flashing > Supports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light in the configured period > Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker > 12V DC/PoE power supply > IP67 protection > SMD Plus > Red and blue flashlight alarm Camera Image Sensor 1/2.8”8Megapixel progressive CMOS Max. Resolution 3840(H) × 2160 (V) ROM 128 MB RAM 512 MB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.007 Lux @ F1.4 S/N Ratio > 56 dB Illumination Distance 30 m (98.4 ft) Illuminator On/Off Control Auto/Manual Illuminator Number 1 (Warm light) Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° Lens Lens Type Fixed-focal Mount Type M12 Focal Length 2.8 mm; 3.6 mm Max. Aperture F1.4 Field of View 2.8 mm: Horizontal 107° × Vertical 56° × Diagonal 127° 3.6 mm: Horizontal 89° × Vertical 46° × Diagonal 102° Iris Type Fixed Close Focus Distance 2.8 mm: 1.5 m (4.9 ft) 3.6 mm: 2.2m (7.2 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8 mm 87.7m (287.7 ft) 35.1 m ( 115.2 ft) 17.5m (57.4 ft) 8.8m (28.8 ft) 3.6 mm 110.3m (361.8 ft) 44.1m (144.7ft) 22.1m (72.5 ft) 11m (36 ft) Professional, intelligent IVS (Perimeter Protection) Tripwire; intrusion (support the classification and accurate detection of vehicle and human) Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) Smart Codec Smart H.265+/Smart H.264+ Video Frame Rate Main stream: 3840 × 2160 @(1–20 fps by default) 3840 × 2160 @(1–25/30 fps with AI function disabled) sub stream: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps) third stream:1280 × 1080 @ (1–25/30 fps) Stream Capability 3 streams Resolution 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps Day/Night Color/B/W BLC Yes HLC Yes WDR 120 dB Scene Self-adaptation (SSA) Yes White Balance Auto/natural/street lamp/outdoor/manual/regional custom Gain Control Auto/Manual Noise Reduction 3D NR Motion Detection OFF/ON (4 areas) Region of Interest (RoI) Yes (4 areas) Smart Illumination Yes Image Rotation 0°/90°/180°/270° (Support with 1920 × 1080 resolution and lower) Mirror Yes Privacy Masking 4 areas Audio Built-in MIC Yes Audio Compression PCM, G.711a, G.711Mu, G726 Alarm Alarm Event No SD card; SD card full; SD card error; service life warning (supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; external alarm; SMD; safety exception; light alarm; sound alarm (11 built-in sounds and custom voices importing)importing) Network Network RJ-45 (10/100 Base-T) SDK and API Yes Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P User/Host 20 (Total bandwidth: 80 M) Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS Browser IE: IE8 and later Chrome Firefox Safari: Safari 12 and later Management Software Smart PSS; DSS; DMSS Mobile Phone IOS; Android Certification Certification CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B Port Audio Input 1 channel (RCA port) Audio Output 1 channel (RCA port) Alarm Input 1 channel in: 5mA 3V–5V DC Alarm Output 1 channel out: 300mA 12V DC Power Power Supply 12V DC/PoE (802.3af) Power Consumption Basic power consumption: 3.1W (DC12V); 3.5W (POE)Max. power consumption (WDR + H.265 + red and blue lights flashing alternately + warm light + sound alarm): 7.8W (DC12V); 8.2W (POE) Environment Operating Conditions –40°C to +60°C (–40°F to +140°F)/Less than 95% RH Storage Conditions –40°C to +60°C (–40°F to +140°F) Protection Grade IP67 Structure Casing Metal Dimensions ?122.0 mm × 110.9 mm (4.8? × 4.4?) Net Weight 754 g (1.7 lb)
